Acidizing Corrosion Inhibitor AC-CI Series Products

Short Description:

AC-CI series acidizing corrosion inhibitors are new Mannich based corrosion inhibitors that has attracted much attention in the industry. Compared with other Mannich base corrosion inhibitors, those new corrosion inhibitors have better dissolution and dispersion in high temperature applications with more significant corrosion inhibition effect and lower cost. The product series covers the application temperature from 90℃ to 180℃.


Product Detail

Product Tags

Product Detail:

Mannich base has been used as an acid corrosion inhibitor on a certain scale and has achieved good results for acidizing application. But with the continuous emergence of high-temperature deep wells, higher requirements have been put forward for corrosion inhibitors. The shortcomings of traditional mannich base, such as easy decomposition at high temperatures and high toxicity of its complex, seriously affect the performance of corrosion inhibitors.To solve those problems, we have developed the new type mannich based AC-CI series acidizing corrosion inhibitors, Compared with traditional acidizing corrosion inhibitors, AC-CI series corrosion inhibitors improved water solubility and the synergistic effect of the complex has further improved the flat spread and film density of the corrosion inhibitor. Moreover, it is unnecessary to add toxic substances such as antimony trichloride during the production process, making it more green and environmentally friendly. At the same time, AC-CI series products strictly controls the production process to ensure that there are no residues of formaldehyde and other aldehydes in the products, fundamentally solving the compatibility problem of early crosslinking of acid thickeners caused by by-products.

Features:

High efficient anti-corrosion with extremely low corrosion rate.
Applicable for 60 °C to above 180 °C acidizing fluid system.
Better water solubility, and better compatibility with acid solution systems.
Zero residues of formaldehyde and other aldehydes by-products.
None toxic substances such as antimony trichloride.

Application :

AC-CI series acidizing corrosion inhibitors are applicable for acid solution systems of hydrochloric acid and mud acid with outstanding anti-corrosion and corrosion inhibition effect on pipelines such as N80, L80, P110, etc.

product
product1

Parameters:

General Temperature Acidizing Corrosion Inhibitor

Product Name

Temperature

Dosage

Acidizing Fluid

Corrosion rate , g/(㎡·h)

Test Standard

AC-CI60

60°C

0.1%

20%HCl

≤1

PetroChina

Standard

SY/T5405-2019

12%HCl+3%HF

≤1

AC-CI90

90°C

0.2%

20%HCl

≤3

12%HCl+3%HF

≤3

High Temperature Acidizing Corrosion Inhibitor

Product Name

Temperature

Dosage

Acidizing Fluid

Corrosion rate , g/(㎡·h)

Test Standard

AC-CI120

120°C

2%

20%HCl

≤25

PetroChina

Standard

SY/T5405-2019

12%HCl+3%HF

≤20

AC-CI140

140°C

3%

20%HCl

≤40

12%HCl+3%HF

≤30

AC-CI160

160°C

4%

20%HCl

≤60

12%HCl+3%HF

≤50

AC-CI180

180°C

5%

20%HCl

≤70

12%HCl+3%HF

≤60
